PRODUCT DESCRIPTION

202 stainless steel pipe is one of the most common stainless steel alloys used in construction, manufacturing and machining worldwide. 202 Stainless steel possesses superior mechanical properties, corrosion resistance and economical manufacturing process, which makes it ideal for many applications. 202 stainless steel is an austenitic chromium-nickel-manganese stainless steel originally developed to save nickel, as a low-cost alternative to more traditional austenitic steel grades, such as 304 and 316. Although it is less strong and corrosion-resistant than these steel grades, it has very good formability and weldability. Generally speaking, 202 Stainless steel pipe is widely used in architectural decoration, municipal engineering, highway guardrail, medical device manufacturing and food processing.


Product Parameters

Product Name202 Stainless Steel Pipe
TypeSteel Pipe
Outer diameterRound Tube4mm-200mm
Square Tube10*10mm-100*100mm
Rectangular Tube10*20mm-50*100mm
Wall Thickness0.6mm-6.0mm
Length1-6 meters, Length can be customized
StandardASTM, AISI, JIS, GB, DIN, EN, etc.
SurfaceBlack, Bright Polished, Rough Turning, Matt Surface Treatment, No. 4. BA, etc.
Scope of ApplicationCommon applications for stainless steel pipes include food processing,Textile operations, Breweries, Water treatment plants, Oil and gas processing,Fertilizers and pesticides, Chemical applications, Construction, Pharmaceuticals, Auto parts, etc.
CertificateISO, SGS, BV, etc.
Production TechnologyHot Rolling, Cold Rolling
Edge ProcessingEdging, Trimming



Chemical Composition

CSiMnCrNiSP
≤ 0.15≤1.07.5~10.017.00~19.004.00~6.00≤ 0.03≤ 0.06



Mechanical Properties

Tensile Strength Kb (MPa)Yield Strength σ0.2 (MPa)Elongation D5 (%)Hardness
≥ 520≥ 275≥40-50≤207HB;≤ 95 HRB;≤218HV



Physical Performance

Density(g/cm³)Modulus of Elasticity(Gpa)Coefficient of Thermal Expansion(10-6/°C)Coefficient of Thermal Conductivity(W/m*K)Resistivity(μohm.in)
7.9320317.516.322
