Outer Diameter

2mm-300mm, or customized

Wall Thickness

0.2mm-50mm, or customized

Length

Customized

Standard

ASTM, AISI, JIS, GB, DIN, EN

Brand

C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, C10930，

C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, C12500, C14200,

C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000,

C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800,

C63020, C65500, C68700, C70400, C70620, C71000, C71500, C71520, C71640, C72200，

T1, T2, T3, TU1, TU0, TU2, TP1, TP2, TAg0.1, ect.

Surface Finish

Grinding, Polishing, Brightening, Oiling, Hair Thread, Brush, Mirror, Sandblasting or Processing As Required

Certification

ISO, SGS, BV

Payment Method

FOB, CRF, CIF, EXW Acceptable

Port of Loading

Any port in China

Delivery Time

Received 30% after deposit 7-15 working days

Copper+Silver

With Ag:

Tin

Sn:

Phosphorus

P:

Lead

Pb:

Nickel

It is:

Iron

Fe:

≥ 99.85

≤ 0.01

0.013~0.050

≤ 0.005

≤≤ 0.01

≤0.05

Antimony

Sb:

Sulphur

S:

Arsenic

As:

Bismuth

Bi:

Oxygen

O:

Impurities:

≤0.002

≤ 0.005

≤ 0.005

≤ 0.002

≤ 0.01

≤ 0.15

Tensile Strength

Kb (MPa):

Elongation

D10 (%):

Hardness:

215~275

≥ 25

55~100HV

Uses and Applications of Copper

Power Industry

Power transmission such as line cables, transformers, switches, plug components and connectors, etc.; motor manufacturing such as stator, rotor, shaft head and hollow wire, etc.; communication cables and residential electrical lines also need to use a large number of copper wires.

Electronic Industry

Electric vacuum devices such as high-frequency and ultra-high-frequency emission tubes, catheters, magnetrons, etc., they need high-purity oxygen-free copper and dispersion-strengthened oxygen-free copper. Copper printed circuits require a large amount of copper foil and copper-based brazing material. Integrationin the circuit

Copper replaces aluminum in silicon chips for interconnect lines and lead frames.

Energy and Petrochemical Industry

The main condenser tube plate and condenser tube of the energy industry thermal power plant are made of brass, bronze or cupronickel. Solar heaters are also often manufactured using copper tubing. Petrochemical industry copper and many copper alloys, used in large quantities to manufacture contact corrosion

Various media containers, piping systems, filters, pumps and valves, various evaporators, heat exchangers and condensers, etc.

Transportation Industry

In the shipbuilding industry, copper alloys include aluminum bronze, manganese bronze, aluminum brass, gunmetal (tin zinc bronze), white copper and nickel copper alloy (Monel alloy), etc. are all standard materials for shipbuilding. In warships and merchant ships, copper and copper alloys are generally used as aluminum bronze propeller,

Bolts, condenser tubes, rivets, copper coated paint, etc. In the automotive industry, copper and copper alloys are mainly used in radiators, brake system pipelines, hydraulic devices, gears, bearings, power distribution and power systems, brake friction plates, washers and various joints,

Accessories and trims, etc. The motors, rectifiers and control, braking, electrical and signal systems on railway trains also rely on copper and copper alloys to work. In addition, the electrification of railways requires a large amount of copper and copper alloys.in the aircraft

Copper for wiring, hydraulic, cooling and pneumatic systems, aluminum bronze tubing for bearing retainers and landing gear bearings, and diamagnetic copper alloy for navigation instruments.

Mechanical and Metallurgical Industries

In addition to a large number of copper used in motors, circuits, hydraulic systems, pneumatic systems and control systems in mechanical engineering, various transmission parts and fixing parts, such as cylinder liners, connectors, fasteners, gears, twisting parts, etc., all Need to reduce wear and lubrication with copper or copper alloy.

The key component in continuous casting technology of metallurgical equipment-crystallizer, mostly made of high strength and high thermal conductivity copper alloy such as chromium copper, silver copper, etc., and the vacuum arc furnace and electroslag furnace water-cooled crucible in electrometallurgy are made of copper pipe, and various induction heating

The induction coils are all made of copper tubes or special-shaped copper tubes, which are cooled by water.

Light Industry

Copper and copper alloy can be used in the manufacture of air conditioner heat exchanger, watch movement, paper machine mesh, roller, printing copper plate, fermentation tank lining, distillation pot, building decoration components, etc.

Emerging Industries and High-tech Fields

Copper is also used in emerging industries and high-tech fields, such as superconducting alloy jackets, ultra-low temperature medium containers and pipelines, rocket engine cooling village, high-energy accelerator magnet windings.
